by gently pressing and correcting if necessary. Once in position, apply pressure to
ensure that the Panel Fixing Tape is in complete contact with the inner faces of both
Mechanical supporting structure.
o ensure the flatness and stability of the cladding panel, ensure that the edge spacing is
maintained properly. The joints must be made at least 8 mm wide so that changes in size can take
place without any obstruction. Flexible mouthpiece 0.3 mm
the table below is depicting maximum spacing of fastening for single and double span panels.
Hidden system or Revit system
The rivets must be put in place with a flexible mouthpiece having clearance of 0.3 mm. The
fastening is placed in such a way that the panel can move slightly. Rivets are put in place with
flexible mouthpieces. The defined clearance of the rivet head to the surface of the panel (0.3 mm)
allows movement of the element in the drill hole as shown in figure. The center point of the drill
hole in the sub-construction must coincide with the center point of the drill hole in the cladding
panels. Drill with a centering piece. Screws must not be over-tightened.
The fastenings should be put in place starting from the middle of panel to outwards.
The table below is depicting maximum spacing of fastening for single and double span
